Fortress V2
Fortress V2 is a commercial ornamental steel fence with a patented pin-hinge racking system and hidden fasteners, for schools, apartments, churches, subdivisions and retail sites.
About Fortress V2
V2 racks to grade with a patented pin-hinge system that avoids metal-on-metal contact, so per Fortress the racking does not compromise the coating. The hidden pin-hinge leaves no visible fasteners, and smooth rails with a true 3/4 in picket give the commercial steel fence a clean profile.
Seven panel styles come in 2 or 3 rails, 90.5 in wide and 34 to 94 in tall, with rackability of 30 in on an 8 ft panel. Rails are 1-9/16 x 1-3/16 in, 14 gauge. Assurance panels with a 3 in air space are offered for playgrounds, pet areas and pools, and Fortress states pool panels meet ICC pool code at select heights. Walk gates are 4 ft and 5 ft, drive gates 6 ft and 8 ft. Black Sand is standard, Gloss Black optional, with a 20-year limited FortressShield coating warranty listed by Fortress.
For a quote, send style, height, rails, post size, footage, gates and finials. Axiom South ships nationwide.
Colors, sizes and specifications
Colors and finishes
- Black Sand (standard)
- Gloss Black (optional)
Sizes and configurations
- Panel length 90.5 in
- Heights 34-94 in depending on style
- Rackability 30 in on an 8 ft panel
- Walk gates 4 and 5 ft; drive gates 6 and 8 ft
- Posts 2.5, 3, 4 in
Models
- Flat Top
- Flat Top/Flat Bottom
- Pressed Spear
- Pressed Spear/Flat Bottom
- Extended Picket
- Extended Picket/Flat Bottom
- Curved Top (each 2 or 3 rail)
- Assurance panels (3 in air space, optional)
Features
- Patented pin-hinge racking without metal-on-metal contact
- Racking does not compromise coating
- Hidden pin-hinge, no visible fasteners
- Smooth rails, true 3/4 in picket
- Simple bracket design
- Pool panels meet ICC pool code at select heights
Specifications
| Rail | 1-9/16 x 1-3/16 in, 14 ga |
|---|---|
| Picket | 3/4 in |
| Gate uprights | 2 in |
| Air space | 3-15/16 in standard; 3 in Assurance |
| Rackability | 30 in |
Accessories and works with
- Nylon, dome and ball caps
- Extensions EX-106/206/306, swivel EXS-106
- Pro Series fork latch, hinges, drop rod
- Finials (fleur de lis, triad, quad)
- Rings
- Readyset cement and grout
Best for
- Schools, daycares, apartments, churches
- Subdivisions, retail parks, restaurants
- Playgrounds, pet areas and pools (Assurance panels)
Installation notes
- Simple bracket design; guides and CAD details on manufacturer site
Warranty
20-year limited manufacturer warranty (FortressShield).
One product or the whole package
Order this on its own, with a few related products, or with everything else for the project. One itemized quote, shipped to all 50 states. Need someone to install it? Find an installer serving your area.
Request a quote for Fortress V2
Send plans, measurements, or photos and we will prepare an itemized quote. You can also call us with questions.
