Joist, Beam & Rafter Hangers
Simpson Strong-Tie joist, beam and rafter hangers in face-mount, top-flange and concealed-flange styles for solid sawn lumber, engineered wood, trusses and masonry.
About Joist, Beam & Rafter Hangers
Hangers are the most common connector on a framing or deck job, and Simpson Strong-Tie makes them for nearly every condition. Styles include face-mount, top-flange and concealed-flange, for solid sawn lumber, engineered wood, plated trusses and masonry.
Popular families include the LUS light-capacity U-shaped hanger with double-shear nailing, the HU heavy face-mount joist hanger, and the HUC and HUCQ concealed-flange hangers, the latter installed with SDS screws. Rafter work is covered by the LRUZ face-mount rafter hanger, LSSR slopeable and skewable rafter hanger, LSSJ jack hanger and HRC hip-ridge connector. Specialty options include DGT and DGHT fire wall hangers, ACBH and CBH concealed beam hangers, the PFUD post-frame hanger and the WMU masonry hanger. Finishes include galvanized, ZMAX and stainless steel depending on model.
Simpson's Hanger Selector web app helps match a hanger to member size and load. For exterior and treated lumber, ask about the right finish. For a quote, send models, member sizes, quantities and nails or screws.
Colors, sizes and specifications
Sizes and configurations
- Face-mount, top-flange and concealed-flange styles
- Hangers for solid sawn lumber, engineered wood, plated trusses and masonry
Models
| Family | Description |
|---|---|
| LUS | Light-capacity U-shaped hanger with double-shear nailing |
| HU | Heavy face-mount joist hanger |
| HUC | Heavy concealed-flange face-mount joist hanger |
| HUCQ | Heavy concealed-flange face-mount joist hanger with SDS screws |
| LRUZ | Face-mount rafter hanger |
| LSSR | Slopeable/skewable rafter hanger |
| LSSJ | Face-mount adjustable light slopeable/skewable jack hanger |
| HRC | Hip-ridge face-mount connector |
| DGT / DGHT | Top-flange fire wall hangers |
| ACBH / CBH | Concealed beam hangers for engineered wood |
| PFUD | Post-frame under-saddle hanger |
| WMU | GFCMU top-flange hanger for masonry |
Features
- Hanger Selector web app helps match a hanger to member size and load
- Fire wall, slopeable/skewable and post-frame hangers available
- Galvanized, ZMAX and stainless steel finish options depending on model
Accessories and works with
- Hanger Selector web app (app.strongtie.com/hs)
- Strong-Drive SD and SDS connector screws
- Connector nails
Best for
- Floor and deck joists to ledgers and beams
- Roof rafters and jack rafters
- Beam-to-post and beam-to-beam connections
- Exterior and treated-lumber applications (ask for the right finish)
