HySecurity StrongArmPark DC
HySecurity StrongArmPark DC is an electromechanical barrier arm operator for parking facilities and traffic control, in 10 ft and 14 ft versions with solar variants.
About HySecurity StrongArmPark DC
Built for parking lanes, StrongArmPark DC runs continuous duty on an electromechanical drive with standard UPS battery backup, delivering up to 1,000 cycles after AC loss from two 12V 8Ah AGM batteries. Solar DCS models are available for off-grid lanes. It carries UL 325 certification, per the manufacturer.
The DC 10 handles arms up to 10 ft with a field-adjustable 1.5, 2 or 2.5 second cycle; the DC 14 takes 10, 12 or 14 ft arms at 2.5, 3 or 3.5 seconds. The arm breaks away when struck and carries LED lighting, reflective red/white stripe tape and a resilient bumper. The Smart DC Controller offers 70+ settings, a 32-character LCD and parking-specific programming. Handing is left-hand standard, field-convertible to right.
Options include arm lights, a HyProtect breakaway bracket with kill switch, and attachment plates for 1 x 4 wood or 2.5 in. square PVC arms. For a quote, share arm length, handing, power source and lane count.
Colors, sizes and specifications
Sizes and configurations
- Arms up to 10 ft (DC10) and 10/12/14 ft (DC14)
- Opens 90 deg +/-10
Models
- StrongArmParkDC 10
- DC 14
- DCS 10 (solar)
- DCS 14 (solar)
Features
- Breakaway arm
- LED-lit arm
- Reflective tape
- Bumper
- 70+ settings, LCD
- Standard UPS battery backup (up to 1000 cycles)
- Solar option
Specifications
| Drive | Electromechanical |
|---|---|
| Duty cycle | Continuous |
| Speed DC10 | 1.5/2/2.5 s |
| Speed DC14 | 2.5/3/3.5 s |
| Battery | Two 12V 8Ah AGM |
| Certification | UL325 |
Accessories and works with
- Attachment plates for 1×4 wood and 2.5 in PVC
- Arm lights
Best for
- Parking facilities
- Traffic control
