Masonry & Concrete Connectors
Simpson Strong-Tie masonry and concrete connectors, including embedded truss anchors, mudsill anchors, retrofit foundation plates, masonry hangers and anchor bolts, for CMU and foundation work.
About Masonry & Concrete Connectors
When wood framing meets masonry or concrete, the connection hardware has to be set right the first time. Simpson Strong-Tie's masonry and concrete connectors cover masonry hangers, truss tiedowns, lateral load transfer, column caps for grouted CMU and concrete piers, foundation and mudsill anchors, anchor bolts, and girder hangers and beam seats.
Truss anchors include the HETA, HHETA and META embedded truss anchors, DETAL and HETAL for lateral loads, the LTA lateral truss anchor and the TSS truss seat snap-in. The HGAM is a hurricane gusset angle for masonry. HU and HUC hangers come in masonry versions. Mudsill anchors include MASOZ and MASOPZ for panel forms and MAB and MASB for CMU block. URFP and FRFP retrofit foundation plates, FWA, FJA and FSA foundation anchors, and SB and SSTB anchor bolts complete the line.
These parts usually come from the structural plans. For a quote, send the connector schedule with models and quantities.
Colors, sizes and specifications
Models
| Family | Description |
|---|---|
| HETA / HHETA / META | Heavy, extra-heavy and medium embedded truss anchors |
| DETAL / HETAL | Dual and heavy embedded truss anchors for lateral loads |
| LTA | Lateral truss anchor |
| TSS | Truss seat snap-in |
| HGAM | Hurricane gusset angle for masonry |
| HU / HUC | Heavy face-mount and concealed-flange joist hangers for masonry |
| MASOZ / MASOPZ | Mudsill anchors (panel form version) |
| MAB / MASB | Mudsill anchors (CMU block version) |
| URFP / FRFP | Universal and flat retrofit foundation plates |
| FWA / FJA / FSA | Foundation wall angle, joist anchor, stud anchor |
| SB / SSTB | Anchor bolts for holdowns and Strong-Wall |
Features
- Categories: masonry hangers, truss tiedowns, lateral load transfer, column caps for GFCMU and concrete piers, foundation anchors, mudsill anchors, anchor bolts, girder hangers/beam seats
Best for
- Masonry and CMU walls with wood roof framing
- Mudsill-to-foundation connections
- Foundation retrofit
